Transmission Jack 1.5 Ton Chain Type TEL15001 BIG RED

Transmission Jack 1.5 Ton Chain Type TEL15001 — BIG RED

The same 1.5 ton Big Red telescopic transmission jack, supplied with a chain type head in place of the standard saddle. The car sits on the lift and the jack rises to meet the gearbox, so the job is done standing rather than lying on the floor.

The Difference Is the Head

Two chains come over the top of the gearbox and pull it down onto the cradle. A plain saddle holds a gearbox by balance alone, so it can shift as the angle changes on the way down. The chains lock the box to the jack before you loosen a single bolt.

Specification

• 1.5 ton capacity.
• Chain type head with twin chains and adjustable clamp arms.
• Telescopic column for working under a vehicle on a lift.
• Tilting saddle to match the gearbox angle.
• Foot pedal pump so both hands stay free.
• Tripod base on three castors for positioning.
• Model TEL15001.

Where It Works Best

• Workshops with a two-post or four-post lift.
• Gearbox, transfer case and differential removal.
• Tall or awkward gearboxes that will not sit steady on a bare saddle.

Safety

A jack lifts a load. It does not hold it. Chain the gearbox to the cradle before loosening any bolt, and never stand under a load supported only by hydraulics.

Buy in Kuwait

Available from Saif Al Arab, Shuwaikh Industrial. Buy online with delivery across Kuwait, or collect from the showroom the same day.
